Generate a star‑field array aligned with generate_sky()

generate_stars.Rd

Render a star map for a given observer location, time, and atmospheric conditions so it can be composited with generate_sky(). Returns a (resolution, 2 * resolution, 4) array with an opaque alpha channel. An image file is written only when filename is supplied.

Usage

generate_stars(
  lon,
  lat,
  datetime,
  filename = NA,
  resolution = 2048,
  turbidity = 3,
  ozone_du = 300,
  altitude = 0,
  color = TRUE,
  star_width = 1,
  upper_hemisphere_only = TRUE,
  atmosphere_effects = TRUE,
  number_cores = 1
)

Arguments

lon

Observer longitude in degrees (east positive).

lat

Observer latitude in degrees.

datetime

POSIXct timestamp used to compute local sidereal time.

filename

Default NA. Path to an image file to write. If NA, the image array is returned without writing.

resolution

Default 2048. Map half-width; the output image is 2 * resolution × resolution.

turbidity

Default 3.0. Atmospheric turbidity controlling aerosol optical depth for extinction/reddening.

ozone_du

Default 300.0. Column ozone in Dobson Units used in atmospheric absorption.

altitude

Default 0.0. Observer altitude above mean sea level in meters.

color

Default TRUE. If TRUE, render RGB star colors; if FALSE, render monochrome luminance.

star_width

Default 1. Approximate stellar point-spread size in pixels (controls apparent star sharpness).

upper_hemisphere_only

Default TRUE. If TRUE, pixels below the local horizon are suppressed to match generate_sky()’s visible hemisphere.

atmosphere_effects

Default TRUE. If TRUE, apply atmospheric extinction and color shift using turbidity, ozone_du, and altitude.

number_cores

Default 1. Number of CPU threads to use.

Value

Either the image array, or the array is invisibly returned if a file is written. The array has dimensions (resolution, 2 * resolution, 4).

Note

Writing to non-EXR formats will introduce precision loss because HDR data are quantised to the destination format, and low dynamic range outputs like PNG and JPEG files will not represent the true luminosity values encoded in the array.

Examples

# Note: exposure has been increased for all examples (via white_point) for
# ease of visibility in documentation

# Basic star field over Washington, DC at a fixed time
if(run_documentation()) {
generate_stars(
  resolution = 400,
  lon        = -77.0369,
  lat        = 38.9072,
  datetime   = as.POSIXct("2025-03-21 02:20:00", tz = "EST"),
  color      = TRUE,
  star_width = 1,
  atmosphere_effects   = TRUE,
  upper_hemisphere_only = TRUE,
  number_cores = 2
) |>
  rayimage::plot_image()
}

if(run_documentation()) {
# Monochrome stars, no atmospheric extinction/reddening, full sphere
generate_stars(
  resolution = 400,
  lon        = -122.4194,
  lat        = 37.7749,
  datetime   = as.POSIXct("2025-06-01 08:00:00", tz = "UTC"),
  color      = FALSE,
  star_width = 1,
  upper_hemisphere_only = FALSE,
  atmosphere_effects    = FALSE
) |>
  rayimage::plot_image()
}

if(run_documentation()) {
# Sharper stars (smaller PSF) with ozone/turbidity and altitude
generate_stars(
  resolution = 400,
  lon        = 10,
  lat        = 45,
  datetime   = as.POSIXct("2025-12-01 22:00:00", tz = "UTC"),
  star_width = 0.5,
  turbidity  = 3.5,
  ozone_du   = 320,
  altitude   = 1000,
  color      = TRUE
) |>
  rayimage::plot_image()
}
