Generate a bright-planet image array — generate

Build a planetary luminance map aligned with the sky dome for compositing within generate_sky_latlong().

Usage

generate_planets(
  datetime,
  lon,
  lat,
  filename = NA,
  resolution = 2048,
  turbidity = 3,
  ozone_du = 300,
  altitude = 0,
  color = FALSE,
  planet_width = 1,
  upper_hemisphere_only = TRUE,
  atmosphere_effects = TRUE,
  number_cores = 1,
  verbose = FALSE
)

Arguments

datetime: POSIXct timestamp used for ephemerides.
lon: Observer longitude in degrees (east positive).
lat: Observer latitude in degrees.
filename: Default NA. Destination image path to write. When NA, the image array is returned without writing.
resolution: Default 2048. Map half-width (image is 2 * resolution × resolution).
turbidity: Atmospheric turbidity for extinction modelling.
ozone_du: Column ozone (Dobson Units) for colour shifts.
altitude: Observer altitude in metres.
color: Render RGB (TRUE) stars or monochrome (FALSE).
planet_width: Approximate point-spread size for planets in pixels.
upper_hemisphere_only: If TRUE, mask pixels below the horizon.
atmosphere_effects: If TRUE, apply atmospheric extinction.
number_cores: CPU threads used for rendering.
verbose: Emit diagnostic output when TRUE.

Value

Either the image array, or the array is invisibly returned if a file is written. The array has dimensions (resolution, 2 * resolution, 4).

Note

Writing to non-EXR formats will introduce precision loss because HDR data are quantised to the destination format, and low dynamic range outputs like PNG and JPEG files will not represent the true luminosity values encoded in the array.

Examples

# Basic star field over Washington, DC at a fixed time
if(run_documentation()) {
generate_planets(
  datetime   = as.POSIXct("2025-03-21 02:20:00", tz = "EST"),
  lon        = -77.0369,
  lat        = 38.9072,
  resolution = 400,
  color      = TRUE,
  planet_width = 1,
  atmosphere_effects   = TRUE,
  upper_hemisphere_only = TRUE,
  number_cores = 2
) |>
  rayimage::plot_image()
}
